MACFAB Drum crusher

The drum crusher can compact empty 220 litre oil drums / barrels into a steel disc. There are slots inside the machine chamber to hold the drum into place during compaction and spikes to punch the drum to drain out any residual oil into a collection tank. The high compaction radio of 5 to 1 gives businesses a massive space saving on their site and in some cases reduced disposal costs. The completely enclosed compaction chamber with safety switches installed on the loading door for safe operation of the machine. There are lifting points for a fork truck built into the base of the drum crusher for easy transport and installation.

Features

  • Reduce your drum disposal costs.
  • High compaction force ratio.
  • Totally enclosed chamber insures high level of safety.
  • 30Lt oil collection tray with tap connection.

Extras

  • Auto compaction option
  • Available with Smaller bale head to compact inside a 200 Lt steel drum.
  • Galvanised finish.

Drum crusher Video

Drum crusher - Drawing

(PDF 204.92 KB)
download

Technical information

An overview of the baler specifications, dimensions, loading aperture and bale size. Please feel free to contact us to confirm any questions you have on the machines specification or performance

COMPACTOR DIMENSIONS
Height: 2.587 m
Width: 1.190 m
Depth: 1.000 m
Weight: 690 kg
Transportation Ht: 1.80 m
COMPACTOR SPECS
Power Supply: 380-400 volt 3-phase
Motor: 11 kW 32 Amp
Pressing Force: up to 24 Ton
Noise Level: 68 decibels
